Product description
Size
1/2 inch - 10 inch
Pressure Rating
150LB-600LB
Standard Connections
Flanged Ends (RF,FF)
Material
Body/Bonnet: A216WCB/A105 ,A351 CF8/F304 ,A351 CF8M/F316 ,ETC.
Ball :A105+ENP,13CR, A351 CF8(A182 F304),A351CF8M(A182 F316) ,ETC
Seat: PTFE, RPTFE, PEEK,NYLON Or Metal to Metal
Features And Benefits
One/ Two/Three Piece
Full or Reduce Bore
Floating Ball,Hollow Or Solid Ball
Fire Safety Seat Sealing
Anti-Static Spring Device
Blow-out proof stem
Low Emission
Locking device (option)
ISO-5211 mounting pad for actuator (option)
Operated by Lever ,Electric.Pneumatic Actuator
Standard
Design and Manufactures: API 6D/ ASME B16.34/ BS 5351/ API 608
Face To Face :ANSI B16.10
End Flange : ANSI B16.5, BW Ends To ANSI B16.25
Fire Safe : API 607 Or API6FA
Checking & Test : API 598
Pressure-Temperature: ASME B16.34
NACE MR-01-75
Product specifications
| Valve type: | Ball Valves |
| Type of Industry: | Valve Manufacturers |
| Valve material: | Stainless Steel |
| Cast Carbon steel | |
| Duplex | |
| Carbon Steel | |
| Cast Iron | |
| Pressure class: | 150 Lbs |
| 900 Lbs | |
| 600 Lbs | |
| 300 Lbs | |
| Valve standards: | DIN (Deutsches Institut für Normung) |
| JIS (Japanese Industrial Valve Standards) | |
| ASME (American Society of Mechanical Engineers) | |
| API (American Petroleum Institute) | |
| Make / Brand: | RXVAL |
Company introduction
Located in Wenzhou City where a hometown of valve in China, Wenzhou Ruixin Valve Co.,Ltd has designed,manufactured,and sold various valves worldwide as the OEM for a number of different brands.
The factory produce valves include Cast Steel & Forge Steel BALL VALVES,GATE VALVES,GLOBE VALVE,CHECK VALVES,STRAINER for power station,petroleum, chemical,natural gas,pharmaceutical industries.
At factory, the Quality Assurance Program meets or exceeds the requirements of API-6D, CE, and ISO9001:2008, You are assured of valve solutions on all valves we sold. Combined with thorough testing and complete customer support, we supply our customers with products of maximum efficiency and minimum long-term costs at a competitive price.
RXV valve warmly welcome foreign customers to visit our factory and build long-term friendly business cooperation.
